CA(M) Self Priming Jet Pumps Twin Impeller

Excluding VAT



Description

The CA(M) series are twin impeller, self-priming centrifugal pumps with cast iron bodies and ejectors. The pumps offer deep suction and a wide pressure range for industrial boosting purposes, while their low operating noise, low power consumption also make them popular for processing and horticultural applications. They are capable of self-priming up to 9 metres, with deeper suction of up to 35 metres possible, by re-fitting the integral ejector to the end of the suction pipe with a foot-valve (not supplied).

For additional frames, please click here

An optional pressure controller will provide dry-run protection and automatic operation. Click here

CAM150

Item codeModelInlet (mm)Outlet (mm)kWVolt (v)Flow (l/min)Head (metres)Width (mm)Length (mm)Height (mm)Dry weight (kg)
19-15-1178CAM1501½"1"1.1230V805822060524028

CA150

Item codeModelInlet (mm)Outlet (mm)kWVolt (v)Flow (l/min)Head (metres)Width (mm)Length (mm)Height (mm)Dry weight (kg)
19-15-1217CA1501½"1"1.1400V805822060524028

CAM200

Item codeModelInlet (mm)Outlet (mm)kWVolt (v)Flow (l/min)Head (metres)Width (mm)Length (mm)Height (mm)Dry weight (kg)
19-15-1258CAM2001½"1"1.5230V1126022060524029

CA200

Item codeModelInlet (mm)Outlet (mm)kWVolt (v)Flow (l/min)Head (metres)Width (mm)Length (mm)Height (mm)Dry weight (kg)
19-15-1056CA2001½"1"1.5400V1126022060524029
