Acuabig Industrial Well Pumps

Description

The Acuabig series are multi-stage pumps for pumping large volumes of water at high pressure, high head in agricultural and industrial applications. They are lubricated and cooled by non-toxic oil. Suitable for pumping potable water and water containing up to 60 g/m³ of suspended solids. Al...

TECHNICAL DATA

  • Outlet (FBSP): 2"
  • Motor output (kW): 0.75 - 1.5
  • Max head (m): 27 - 57
  • Phases: 1
  • Max flow (I/min): 195
  • Bore hole (size): 5"
Skip to product information
1 of 3
Regular price £617.00 GBP
Regular price Sale price £617.00 GBP
Sale Sold out
Excluding VAT
View full details
PERFORMANCE CURVE
SPECIFICATIONS

Specifications

item code

model

Manual or Auto

outlet (FBSP)

kW

volt

flow (l/min)

head

(mtrs)

dia x h (mm)

bore hole

(size)

dry weight

(kgs)

22-10-1027

Acuabig 2-200

M

2"

0.75

230

195

27

Ø127x455

5”

12.0

22-10-1002

Acuabig 2-200

A

2”

0.75

230

195

27

Ø127x455

5”

12.3

22-10-1013

Acuabig 3-200

M

2”

1.1

230

195

43

Ø127x525

5”

13.0

22-10-1024

Acuabig 3-200

A

2"

1.1

230

195

43

Ø127x525

5”

13.3

22-10-1016

Acuabig 4-200

M

2”

1.5

230

195

57

Ø127x600

5”

15.0

22-10-1001

Acuabig 4-200

A

2”

1.5

230

195

57

Ø127x600

5”

15.3

model

w X l X h (mm)

Acuabig 2-200

127x127x455

Acuabig 3-200

127x127x525

Acuabig 4-200

127x127x600
