CX(M) Centrifugal Surface Pump

Excluding VAT


Description

The CX(M) series are non self priming, single-stage, centrifugal pumps with 304 stainless steel pump bodies, impellers and motor shafts. There fitted with silicon carbide and Viton mechanical seals. Motor frame and supports are in aluminium and the fan covers are in steel. Motor protection is IP55. Single phase motors incorporate an overload protection device. They are designed for pressure boosting, water supply, treatment and irrigation, air-conditioning and general transfer applications up to a maximum of 90°C. They can pump moderately aggressive liquids. With the addition of a foot-valve, they are capable of suction lift of 7 meters. They are designed for many domestic, industrial and agricultural applications.

CXM 250/1.5

ModelInlet (BSPF)Outlet (BSPF)KWVolt (v)Flow (I/min)Head (Mtrs)W x L x H (mm)Dry weight (kgs)
CXM 250/1.51 ½1 ¼1.523048025415x216x25320
