KRSU Large Solids Submersible Pump

Excluding VAT

Notify me when this product is available:

Description


The  KRSU822 is a three phase drainage pump with a large solids passage capacity, designed specifically for temporary over-pumping during sewer refurbishment. Constructed in superior grade materials throughout to give exceptional performance in harsh operating conditions, its narrow shape and top discharge enables it to be fitted within a manhole. The hydraulic design features a double mechanical seal, with an oil lifter, for positive seal lubrication in any operating position. It has a generous solids capacity. The high-performance motor features internal overload protection and is cooled by a water jacket that assures efficient motor cooling even when exposed to air.

KRSU822

item code

model

Manual or Auto

outlet (flange/mm)

kW

volt

flow (l/min)

head

(mtrs)

free passage (mm)

w x l x h

(mm)

dry weight

(kgs)

10-10-1268

KRSU822

M

200

22

400

5700

26.5

56

500x546x1486

380
