LH Submersible Dewatering Pumps

Excluding VAT

Description

The LH series are three-phase contractors’ pumps capable of very high heads. Constructed in superior grade materials throughout to give exceptional performance in harsh operating conditions. The hydraulic design features a double mechanical seal, with a patented oil lifter, for positive seal lubrication in any operating position. The top discharge design forms a water and air-cooling channel and this, combined with a high-performance motor, enables long periods of operation in seepage conditions. With this design, the base is small, which enables good positioning in confined spaces. Maintenance is straightforward, with simple replacement of parts, without the need for special tools. High-performance motors feature internal overloads, enabling simple installation and direct connection to the power supply.

Supplied with 20 metres of heavy-duty rubber power cable, although IDS (individually screened cable) is available on most models (at an extra cost) for quarry and mining applications.

LH33.0

Item CodeModelManual / AutoOutlet (mm)kWVolt (V)Flow (l/min)Head (metres)Max Water Depths (metres)Free Passage (mm)Dia x H (mm)Dry weight (kg)
10-10-1182LH33.0Manual3" BSPM3400V100018306∅185 x 64542

LH615

Item CodeModelManual / AutoOutlet (mm)kWVolt (V)Flow (l/min)Head (metres)Max Water Depths (metres)Free Passage (mm)Dia x H (mm)Dry weight (kg)
10-10-1021LH615Manual15015400V240052306∅330 x 1014213

LH637

Item CodeModelManual / AutoOutlet (mm)kWVolt (v)Flow (l/min)Head (metres)Max Water Depths (metres)Free Passage (mm)Dia x H (mm)Dry weight (kg)
10-10-1174LH637Manual15037400V237590306∅530 x 1448495

LH837

Item CodeModelManual / AutoOutlet (mm)kWVolt (v)Flow (l/min)Head (metres)Max Water Depths (metres)Free Passage (mm)Dia x H (mm)Dry weight (kg)
10-10-1123LH837Manual20037400V5400523020∅530 x 1488495

LH645

Item CodeModelManual / AutoOutlet (mm)kWVolt (v)Flow (l/min)Head (metres)Max Water Depths (metres)Free Passage (mm)Dia x H (mm)Dry weight (kg)
10-10-1151LH645Manual15045400V300090306∅530 x 1448510

LH845

Item CodeModelManual / AutoOutlet (mm)kWVolt (v) Flow (l/min)Head (metres)Max Water Depths (metres)Free Passage (mm)Dia x H (mm)Dry weight (kg)
10-10-1061LH845Manual20045400V5500523020∅530 x 1488510

LH690

Item CodeModelManual / AutoOutlet (mm)kWVolt (v)Flow (l/min)Head (metres)Max Water Depths (metres)Free Passage (mm)Dia x H (mm)Dry weight (kg)
10-10-1140LH690Manual15090400V2455149306∅595 x 17871100

LH890

Item CodeModelManual / AutoOutlet (mm)kWVolt (v)Flow (l/min)Head (metres)Max Water Depths (metres)Free Passage (mm)Dia x H (mm)Dry weight (kg)
10-10-1103LH890Manual20090400V6000893020∅595 x 17871150
