RSX(M)2 Horizontal Multistage Pumps

Excluding VAT


Description

RSX(M)2 are non self-priming, multi-stage, horizontal centrifugal pumps with all the components that are in contact with the liquid constructed in 304 stainless steel.  For the pumping of clean water only, they can develop high pressures and lifts from comparatively small motors and operate virtually silent, they are designed for industrial, commercial and processing applications.

Optional pressure controller and inverter drives will provide dry-run protection, automatic and energy efficient operation. (Sold separately.)

RSXM 2-4

Item codeModelInlet (BSPF)Outlet (BSPF)kWVolt (v)Flow (l/min)Head (metres)Width (mm)Length (mm)Height (mm)Dry weight (kg)
19-15-1205RSXM2-41"1"0.5523080361433622169.5

RSX 2-4

Item code ModelInlet (BSPF)Outlet (BSPF)kWVolt (v)Flow (l/min)Head (metres)Width (mm)Length (mm)Height (mm)Dry weight (kg)
19-15-1023 RSX2-41"1"0.5540080361433622169.5

RSXM 2-5

Item code ModelInlet (BSPF)Outlet (BSPF)kWVolt (v)Flow (l/min)Head (metres)Width (mm)Length (mm)Height (mm)Dry weight (kg)
19-15-1133 RSXM2-51"1"0.5523080451433802169.5

RSX 2-5

Item code ModelInlet (BSPF)Outlet (BSPF)kWVolt (v)Flow (l/min)Head (metres)Width (mm)Length (mm)Height (mm)Dry weight (kg)
19-15-1100 RSX2-51"1"0.5540080451433802169.5

RSXM 2-6

Item code ModelInlet (BSPF)Outlet (BSPF)kWVolt (v)Flow (l/min)Head (metres)Width (mm)Length (mm)Height (mm)Dry weight (kg)
19-15-1040 RSXM2-61"1"0.75400805514339821610.5

RSX 2-6

Item code ModelInlet (BSPF)Outlet (BSPF)kWVolt (v)Flow (l/min)Head (metres)Width (mm)Length (mm)Height (mm)Dry weight (kg)
19-15-1220 RSX2-61"1"0.75400805514339821610.5
