SQ2-2 Stainless Steel Drainage Water Pump

Excluding VAT

Description

The SQ2-2 series is constructed in 304 and 316 stainless steel and resin. Models have a water cooled, top discharge design for applications where space is limited, operating while partially submerged or during short periods of dry running. Liquid paraffin is used for the lubrication oil, which enables use in food processing and aquaculture, but they are suitable for use in applications where chemical and corrosion resistance is required at a higher head and greater volume than basic stainless-steel pumps. For use in domestic, trade and industrial applications, but not recommended for ponds or water features.


* The selection of a pump must initially meet the basic corrosion resistant standards, however additional mechanical or physical properties in the duty may also need to be considered to achieve the overall service performance required. Please contact our sales department for guidance before selection.

SQ2-2

item code

model

Manual or Auto

outlet (mm)

kW

volt

flow (l/min)

head

(mtrs)

free passage (mm)

dia x h (mm)

dry weight

(kgs)

10-10-1263

50SQ2-2.4S

M

50

0.40

230

240

10.5

6

Ø180x366

10.5

10-10-1278

50SQ2-2.4

M

50

0.40

400

240

10.5

6

Ø180x366

10.5

10-10-1291

50SQ2-2.75

M

50

0.75

400

300

14.5

6

Ø180x388

12.0
