SV Portable Submersible Pumps

Excluding VAT

Description

The SV series have vortex impellers and large pump casings for pumping light effluent, sewage and waste containing fibrous material, submerged debris and solids. Due to impeller material, SV-150(A/V) and SV-250(A/V)are suited to pumping soft and floating solids, but the SV-400(A) and SV-750(A) can pump hard solids and have base plates for portable use. For SV-750 models, a 89mm lever lock connection kit with a galvanised iron extension pipe, is an optional extra. Available as manual or with a pendant float switch, for automatic operation. SV-150(V)and SV-250(V) have a tube type float switch for narrow sump applications. SV pumps are not recommended for ponds or water features.

SV-150A

item code model Manual or outlet kW volt flow (l/min) head (mtrs) free passage (mm) w x l x h (mm) on level (mm) off level (mm) dry weight (kgs)
Auto (mm)
15-10-1050 SV-150A 32 0.15 230 170 5.7 27 145x205x390 345 100 8.00

*Approximate Liquid Level

    SV-150V

    item code model Manual or outlet kW volt flow (l/min) head (mtrs) free passage (mm) w x l x h (mm) on level* (mm) off level* (mm) dry weight (kgs)
    Auto (mm)
    15-10-1048 SV-150V A(V) 32 0.15 230 170 5.7 27 200x205x390 230 130 8.00

    *Approximate Liquid Level

      SV-250(A)

      item code model Manual or outlet kW volt flow (l/min) head (mtrs) free passage (mm) w x l x h (mm) on level (mm) off level (mm) dry weight (kgs)
      Auto (mm)
      15-10-1043 SV-250 32 0.25 230 220 7.5 27 145x205x390 9.20
      15-10-1057 SV-250A 32 0.25 230 220 7.5 27 145x205x390 345 * 100 * 9.45
      15-10-1110 SV-250V A(V) 32 0.25 230 220 7.5 27 200x205x390 230 130 9.45

      *Approximate Liquid Level

        SV-400(A)

        item code model Manual or outlet kW volt flow (l/min) head (mtrs) free passage (mm) w x l x h (mm) on level (mm) off level (mm) dry weight (kgs)
        Auto (mm)
        15-10-1018 SV-400 50 0.4 110 350 35 160x215x420 11.30
        15-10-1028 SV-400 50 0.4 230 350 35 160x215x420 11.30
        15-10-1070 SV-400A 50 0.4 110 350 35 160x215x420 385 * 150 * 11.55
        15-10-1023 SV-400A 50 0.4 230 350 35 160x215x420 385 * 150 * 11.55

        *Approximate Liquid Level

          SV-750(A)

          item code model Manual or outlet kW volt flow (l/min) head (mtrs) free passage (mm) w x l x h (mm) on level (mm) off level (mm) dry weight (kgs)
          Auto (mm)
          15-10-1081 SV-750 75 0.75 110 420 11 37 165x265x440 17.15
          15-10-1016 SV-750 75 0.75 230 420 11 37 165x265x440 17.15
          15-10-1031 SV-750A 75 0.75 110 420 11 37 165x265x440 415 * 170 * 17.40
          15-10-1083 SV-750A 75 0.75 230 420 11 37 165x265x440 415 * 170 * 17.40

          *Approximate Liquid Level

            Lever Lock

            item code

            26-85-1000
