TDS Semi Trash Pumps

Excluding VAT

Description

For applications where water contains solids, centrifugal trash pumps are recommended. The TDS-HA and TED-HA models are self-priming pumps powered by 4 stroke Honda petrol engines with oil alerts. All models have a lightweight pump end and engine, housed within a protective tubular steel, easy carry frame. They are available in the following designs, with differing inspection and impeller access designs:

TDS-50HA and TDS-80HA are semi-trash pumps. The pump housing features elongated bolts for easy removal using the special tool supplied. These models are able to handle 20mm solids which is 12mm more than the Koshin alternative (SEH50T and 80T).

TDS-50HA

Item Code

Model

Inlet (mm)

Outlet (mm)

Engine

Fuel

HP

Oil Alert

Flow (l/min)

Head (metres)

Solids (mm)

Width (mm)

Length (mm)

Height (mm)

Dry weight (kg)

18-20-1019

TDS-50HA

50

50

GX120

Petrol Engine

4

Yes

780

23

20

345

470

420

24

    TDS-80HA

    Item CodeModelInlet (mm)Outlet (mm)EngineFuelHPOil AlertFlow (l/min)Head (metres)Solids (mm)Width (mm)Length (mm)Height (mm)Dry weight (kg)
    18-20-1005TDS-80HA8080GX160Petrol Engine5.5Yes1150232037052542027
