Acuasub Submersible Multi Stage Borehole Pumps

Excluding VAT

Description

The Acuasub series are multi-stage pumps for high pressure, high head pumping in agricultural and industrial applications. They are lubricated and cooled by non-toxic oil. Suitable for pumping potable water and water containing up to 60 g/m³ of suspended solids. Supplied with an external, inline starter and thermal protection box. Flow can be controlled by including a pressure switch in the delivery line (see here).

A stainless steel sand filter, with a mesh size of 80 microns, is available as an optional extra to prevent damage to the pump from abrasive solids.

Acuasub

Item Code

Model

Outlet (FBSP)

kW

Volt (V)

Flow (l/min)

Head (metres)

Dia x H (mm)

Bore hole (size)

Dry weight (kg)

22-10-1030

Acuasub 55/100

1 1/4"

0.75

230

45

100

∅99 x 672

4"

13

22-10-1005

Acuasub 55/140

1 1/4"

1.1

230

45

140

∅99 x 830

4"

14

22-10-1029

Acuasub 100/70

1 1/4"

0.75

230

90

70

∅99 x 565

4"

13

22-10-1010

Acuasub 100/100

1 1/4"

1.1

230

90

100

∅99 x 680

4"

15

Sand filter

Item CodeModel
22-85-1000Sand filter
