Acuasystem 2 AL Rainwater & Dry Submersible Pumps

Excluding VAT

Description

Acuasystem are multi stage pumps that can be used as submersibles in rainwater harvesting systems and wells, and also on the surface, or “dry mounted” in unventilated areas and rooms with moist atmospheres or liable to flooding. For operation in dry applications, they are designed to be virtually silent. They are suitable for potable water and water containing up to 60 g/m³ of suspended solids.


All models have integral starting capacitors. Available as manual or with a pendant float switch, for automatic operation, flow on the manual version can be controlled by including a pressure controller in the delivery line (see more).

For submersible applications, a floating suction set enables draining water from a tank without sucking in debris from the bottom.

Acuasystem

 item code

model

Manual

or Auto

outlet (FBSP)

kW

volt

flow (l/min)

head

(mtrs)

base dia x h (mm)

case diameter

(mm)

dry weight

(kgs)

22-10-1007

Acuasystem 2AL 30

M

1"

0.55

230

90

33

Ø190x528

127-175

12.0

22-10-1040

Acuasystem 2AL 30

A

1"

0.55

230

90

33

Ø190x528

127-175

12.3

22-10-1003

Acuasystem 2AL 60

M

1"

0.75

230

90

55

Ø190x607

127-175

13.0

22-10-1014

Acuasystem 2AL 60

A

1"

0.75

230

90

55

Ø190x607

127-175

13.3

22-10-1020

Acuasystem 2AL 80

M

1"

1.2

230

90

75

Ø190x727

127-175

15.0

22-10-1028

Acuasystem 2AL 80

A

1"

1.2

230

90

75

Ø190x727

127-175

15.3

22-10-1023

Acuasystem 2AL 150

M

1"

0.75

230

130

45

Ø190x607

127-175

13.1

22-10-1035

Acuasystem 2AL 150

A

1"

0.75

230

130

45

Ø190x607

127-175

13.4

22-10-1009

Acuasystem 2AL 170

M

1"

1.2

230

130

65

Ø190x727

127-175

15.1

22-10-1006

Acuasystem 2AL 170

A

1"

1.2

Floating Suction Set

 12-85-1035

Optional extra: Floating suction set (6 bar) c/w 2 metres of 25mm hose
