Acuatec High Pressure Well Pumps

Excluding VAT



Description

The Acuatec series are multi-stage pumps for high pressure, high head pumping in agricultural and industrial applications. They are lubricated and cooled by non-toxic oil. Suitable for pumping potable water and water containing up to 60 g/m³ of suspended solids. All models have integral starting capacitors. Available as manual or with a pendant float switch, for automatic operation, flow on the manual version can be controlled by including a pressure controller in the delivery line (see here).

Acuatec

 item code

model

Manual

or Auto

outlet (BSPF)

kW

volt

flow (l/min)

head

(mtrs)

dia x h (mm)

bore hole

(size)

dry weight

(kgs)

22-10-1031

Acuatec 40

M

1¼"

0.6

230

90

33

Ø127x420

5"

12.0

22-10-1004

Acuatec 40

A

1¼"

0.6

230

90

33

Ø127x420

5”

12.3

22-10-1015

Acuatec 60

M

1¼"

0.9

230

90

55

Ø127x490

5”

13.0

22-10-1019

Acuatec 60

A

1¼"

0.9

230

90

55

Ø127x490

5”

13.3

22-10-1034

Acuatec 80

M

1¼"

1.2

230

90

75

Ø127x570

5”

15.0

22-10-1021

Acuatec 80

A

1¼"

1.2

230

90

75

Ø127x570

5”

15.3

22-10-1041

Acuatec 160

M

1¼"

0.9

230

135

53

Ø127x605

5”

14.0

22-10-1043

Acuatec 160

A

1¼"

0.9

230

135

53

Ø127x605

5”

14.3

22-10-1042

Acuatec 170

M

1¼"

1.2

230

135

68

Ø127x649

5”

15.0

22-10-1044

Acuatec 170

A

1¼"

1.2

230

135

68

Ø127x649

5”

15.3
