CX 40 Single Stage Centrifugal Pumps

Excluding VAT


Description

The CX series are stainless steel, single-stage, mono-bloc, non self-priming centrifugal pumps manufactured in accordance with dimensional standards DIN-EN 733 (formerly DIN 24255), UNI 7467 and NF E44-111. They have a “back pull out” design, for ease of maintenance, which enables the pump body to be removed without disconnecting it from the pipework. It also allows the unit to be installed in any position, except with the inlet facing down. For pumping hot or cold clean water in industrial and agricultural applications, they are designed for circulation, pressurisation, water supply and transfer. Optional pump control and energy management systems are available (see here).

CX40- 160/4

Item CodeModelKWFlow (l/min)Head (metres)DNMDNAABCEFGHH1H2N
19-15-1123CX40-160/4480033406534795011601570280112142230

CX40- 200/5.5

Item CodeModelKWFlow (l/min)Head (metres)DNMDNAABCEFGHH1H2N
19-15-1157CX40-200/5.55.590044406547995652121570345160184297

CX40- 200/7.5

Item CodeModelKWFlow (l/min)Head (metres)DNMDNAABCEFGHH1H2N
19-15-1136CX40-200/7.57.5100054406547995652121570345160184297
