£463.00 GBP
Excluding VAT
The DSPK range of cutter pumps are for sewage where destructible solids need to be reduced and pumped over a short or medium distance. The impeller rotates against a serrated suction cover to cut solids before pumping. Supplied as standard free-standing, an optional auto coupling set is available for guide rail mounting. Single-phase models are available with or without a float switch.
| Item Code | Model | Outlet (mm) | kW | Volt (v) | Flow (l/min) | Head (metres) | Free Passage (mm) | Width (mm) | Length (mm) | Height (mm) | Dry weight (kg) |
| 15-10-1098 | DSPK-10 | 50 | 0.75 | 110 | 430 | 13 | 20 | 190 | 255 | 445 | 19.9 |
| 15-10-1104 | DSPK-10 | 50 | 0.75 | 230 | 430 | 13 | 20 | 190 | 255 | 445 | 19.9 |
| 15-10-1085 | DSPK-10 - Auto | 50 | 0.75 | 230 | 430 | 13 | 20 | 190 | 255 | 445 | 21 |
| 15-10-1063 | DSPK-20 | 80 | 1.5 | 230 | 700 | 15 | 20 | 190 | 255 | 455 | 38 |
| 15-10-1067 | DSPK-20 | 80 | 1.5 | 400 | 700 | 15 | 20 | 190 | 255 | 455 | 38 |
| 15-10-1029 | DSPK-20 - Auto | 80 | 1.5 | 230 | 700 | 15 | 20 | 190 | 255 | 455 | 39 |
| 15-10-1015 | DSPK-30 | 3" | 2.2 | 400 | 1200 | 20 | 40 | 245 | 430 | 625 | 58 |
| 15-10-1068 | DSPK-50 | 3" | 3.7 | 400 | 1300 | 22 | 40 | 245 | 430 | 655 | 60 |
| 15-10-1078 | DSPK-75 | 4" | 5.5 | 400 | 2100 | 24 | 50 | 300 | 505 | 770 | 105 |
| 15-10-1053 | DSPK-100 | 4" | 7.5 | 400 | 2500 | 27 | 65 | 300 | 505 | 815 | 117 |
