KRS2 Submersible Drainage Slurry Pump

Excluding VAT

Description

KRS2 models are three-phase slurry pumps, in cast iron, with a built-in agitator to stir sand, bentonite and pulverized solids into suspension for pumping. Capable of pumping large volumes, motors are 4 pole for increased wear resistance, they have a generous solids capacity. Constructed in superior grade materials throughout, they give exceptional performance in harsh operating conditions. The hydraulic design features a double mechanical seal, with a patented oil lifter, for positive seal lubrication in any operating position. The top discharge design forms a water and air-cooling channel and this, combined with a high-performance motor, enables long periods of operation in seepage conditions. Maintenance is straightforward, with simple replacement of parts, without the need for special tools. High-performance motors feature internal overloads, enabling simple installation and direct connection to the power supply.

All models are supplied with 20 metres of heavy duty rubber power cable although IDS (individually screened cable) is available, at an extra cost, on all models, for quarry and mining applications. Each model is supplied with a hose connector in cast iron.

KRS2-80

Item CodeModelOutlet (mm)kWVolt (v)Flow (l/min)Head (metres)Free Passage (mm)Width (mm)Length (mm)Height (mm)Dry weight (kg)
10-10-1212KRS2-8080440016501630326350766105

KRS2-100

Item CodeModelOutlet (mm)kWVolt (v)Flow (l/min)Head (metres)Free Passage (mm)Width (mm)Length (mm)Height (mm)Dry weight (kg)
10-10-1001KRS2-100100640023501730373415754145

KRS2-150

Item CodeModelOutlet (mm)kWVolt (v)Flow (l/min)Head (metres)Free Passage (mm)Width (mm)Length (mm)Height (mm)Dry weight (kg)
10-10-1240KRS2-150150940032002230407434811170

KRS2-200

Item Code

Model

Outlet (mm)

kW

Volt (v)

Flow (l/min)

Head (metres)

Free Passage (mm)

Width (mm)

Length (mm)

Height (mm)

Dry weight (kg)

10-10-1239

KRS2-200

200

18

400

4300

31

30

530

576

1181

395
