KTV Drainage Pumps

Excluding VAT

Description

The KTV series is a range of lightweight, three-phase, contractors’ pumps, which are constructed in superior grade materials throughout to give exceptional performance in harsh operating conditions. The hydraulic design features a double mechanical seal, with a patented oil lifter, for positive seal lubrication in any operating position. The top discharge design forms a water and air-cooling channel and this, combined with a high-performance motor, enables long periods of operation in seepage conditions. Maintenance is straightforward, with simple replacement of parts, without the need for special tools. High-performance motors feature internal overloads, enabling simple installation and direct connection to the power supply.

KTV2-8

Item CodeModelOutlet (mm)kWVolt (v)Flow (l/min)Head (metres)Free Passage (mm)Dia x H (mm)Dry weight (kg)
10-10-1167KTV2-82" BSPM & 500.75400320156∅200 x 36911.5

KTV2-15

Item CodeModelOutlet (mm)kWVolt (v)Flow (l/min)Head (metres)Free Passage (mm)Dia x H (mm)Dry weight (kg)
10-10-1236KTV2-152" BSPM & 501.5400425208.5∅240 x 39619.5

KTV2-22

Item CodeModelOutlet (mm)kWVolt (v)Flow (l/min)Head (metres)Free Passage (mm)Dia x H (mm)Dry weight (kg)
10-10-1029KTV2-222" BSPM & 502.2400525248.5∅240 x 41623

KTV2-37

Item CodeModelOutlet (mm)kWVolt (v)Flow (l/min)Head (metres)Free Passage (mm)Dia x H (mm)Dry weight (kg)
10-10-1134KTV2-373" BSPM & 803.7400830268.5∅285 x 51034

KTV2-37H

Item CodeModelOutlet (mm)kWVolt (v)Flow (l/min)Head (metres)Free Passage (mm)Dia x H (mm)Dry weight (kg)
10-10-1200KTV2-37H2" BSPM & 503.7400500348.5∅285 x 51034

KTV3-55

Item Code

Model

Outlet (mm)

kW

Volt (v)

Flow (l/min)

Head (metres)

Free Passage (mm)

Dia x H (mm)

Dry weight (kg)

10-10-1137

KTV3-55

3" BSPM & 80

5.5

400

980

35

8.5

∅300 x 545

46.5
