KTV2 Slurry Pumps with Agitator

Excluding VAT

Description

The KTV2 pumps are portable three phase slurry pumps, in lightweight aluminium, with a built-in agitator to stir sand, silt and pulverized solids into suspension for pumping. Constructed in superior grade materials throughout, they give exceptional performance in harsh operating conditions. The hydraulic design features a double mechanical seal, with an oil lifter, for positive seal lubrication in any operating position. The top discharge design forms a water and air-cooling channel and this, combined with a high-performance motor, enables long periods of operation in seepage conditions. Maintenance is straightforward, with simple replacement of parts, without the need for special tools. High-performance motors feature thermal protection, enabling simple installation and direct connection to the power supply.

KTV2-50

Item CodeModelOutlet (BSPM & mm)kWVolt (v)Flow (l/min)Head (metres)Free Passage (mm)Width (mm)Length (mm)Height (mm)Dry weight (kg)
10-10-1227KTV2-502" BSPM & 502400425201025025045424

KTV2-80

Item Code

Model

Outlet (BSPM & mm)

kW

Volt (v)

Flow (l/min)

Head (metres)

Free Passage (mm)

Width (mm)

Length (mm)

Height (mm)

Dry weight (kg)

10-10-1146

KTV2-80

3" BSPM & 80

3

400

725

23

10

295

295

550

37
