NK High Head Submersible Water Pump

Excluding VAT

Description

The NK Series are single phase drainage pumps capable of large flows at high heads. Constructed in superior grade materials throughout they give exceptional performance in harsh operating conditions. The hydraulic area features a double mechanical seal, with an oil lifter, for positive seal lubrication in any operating position. The top discharge design forms a water and air-cooling channel and this, combined with a high-performance motor, enables long periods of operation in seepage conditions. Each model has an integral starting capacitor.

NK

item code

model

Manual

or Auto

outlet (BSPM)

kW

volt

flow (l/min)

head

(mtrs)

free passage (mm)

w x l x h

(mm)

dry weight

(kgs)

10-10-1266

NK4-22

M

2"

2.2

230

525

24

6

194x243x614

29

10-10-1281

NK3-22L

M

3"

2.2

230

800

18

6

216x235x669

40
