NKZ Agitator Submersible Water Pump

Excluding VAT

Description

NKZ models are three-phase slurry pumps, in cast iron, with a built-in agitator to stir sand, bentonite and pulverized solids into suspension for pumping. Capable of pumping large volumes at high heads, motors are 4 pole for increased wear resistance, they have a generous solids capacity. Constructed in superior grade materials throughout, they give exceptional performance in harsh operating conditions. The hydraulic design features a double mechanical seal, with a patented oil lifter, for positive seal lubrication in any operating position. The spiral shape of the pump casing, an air and water channel around the motor and the air-release valve, all combine to provide smooth, anti-clog pumping. Maintenance is straightforward, with simple replacement of parts, without the need for special tools. High-performance motors feature internal overloads, enabling simple installation and direct connection to the power supply.

All models are supplied with 20 metres of heavy duty rubber power cable although IDS (individually screened cable) is available, at an extra cost, on most models, for quarry and mining applications. Each model is supplied with a hose connector in cast iron.

NKZ3-C3

Item CodeModelOutlet (mm)kWVolt (v)Flow (l/min)Head (metres)Free Passage (mm)Width (mm)Length (mm)Height (mm)Dry weight (kg)
10-10-1209NKZ3-C3 - 400V3"2.240093012.63046737066491

NKZ3-D3

Item CodeModelOutlet (mm)kWVolt (v)Flow (l/min)Head (metres)Free Passage (mm)Width (mm)Length (mm)Height (mm)Dry weight (kg)
10-10-1009NKZ3-D3 - 400V3"3.740015401730467370664100

NKZ3-80H

Item CodeModelOutlet (mm)kWVolt (v)Flow (l/min)Head (metres)Free Passage (mm)Width (mm)Length (mm)Height (mm)Dry weight (kg)
10-10-1018NKZ3-80H - 400V3"5.5400153024.920491401754132

NKZ3-100H

Item CodeModelOutlet (mm)kWVolt (v)Flow (l/min)Head (metres)Free Passage (mm)Width (mm)Length (mm)Height (mm)Dry weight (kg)
10-10-1205NKZ3-100H - 400V4"11400244028.820547414841196
