RA(M) Horizontal Centrifugal Pumps

Excluding VAT


Description

The RA(M) are self-priming, multi-stage, horizontal centrifugal pumps with 304 stainless steel pump casings, cast iron pump bodies and cast iron motor supports. Impellers and diffusers are in thermoplastic. They have 304 stainless steel shafts, fitted with carbon ceramic (models 3-4-5) or silicon carbide (models 40-50) and NBR mechanical seals.  Motor frame and supports are in aluminium and the fan covers are in steel. Motor protection is IP44 (models 3-4-5) or IP55 (models 40-50).  Single phase motors incorporate an overload protection device.   They can develop high pressures and lifts from comparatively small motors and operate virtually silent, hence they are suitable for many domestic, industrial and horticultural applications. With the addition of a foot-valve, they are capable of suction lifts of 7 metres. They are designed for pumping clean water only up to a maximum of 35ºC.

RAM3

Item codeModelOutlet (mm)kWVolt   (v)Flow (l/min)Head (metres)Inlet (mm)Width (mm)Length (mm)Height (mm)Dry weight (kg)
19-15-1198RAM3 1" BSPF0.623090341" BSPF18039818513

RAM4

Item codeModelOutlet (mm)kWVolt   (v)Flow (l/min)Head (metres)Inlet (mm)Width (mm)Length (mm)Height (mm)Dry weight (kg)
19-15-1009RAM41" BSPF0.723090451" BSPF18042218514

RAM5

Item codeModelOutlet (mm)kWVolt   (v)Flow (l/min)Head (metres)Inlet (mm)Width (mm)Length (mm)Height (mm)Dry weight (kg)
19-15-1120RAM5 1" BSPF1.123090601" BSPF18044618515

RA5

Item codeModelOutlet (mm)kWVolt   (v)Flow (l/min)Head (metres)Inlet (mm)Width (mm)Length (mm)Height (mm)Dry weight (kg)
19-15-1160RA51" BSPF1.140090601" BSPF18044618615

RAM40

Item codeModelOutlet (mm)kWVolt   (v)Flow (l/min)Head (metres)Inlet (mm)Width (mm)Length (mm)Height (mm)Dry weight (kg)
19-15-1106RAM401" BSPF1.5230160491¼" BSPF19453324222

    RA40

    Item codeModelOutlet (mm)kWVolt   (v)Flow (l/min)Head (metres)Inlet (mm)Width (mm)Length (mm)Height (mm)Dry weight (kg)
    19-15-1167RA40 1" BSPF1.5400160491¼" BSPF19453324222

      RAM50

      Item codeModelOutlet (mm)kWVolt   (v)Flow (l/min)Head (metres)Inlet (mm)Width (mm)Length (mm)Height (mm)Dry weight (kg)
      19-15-1137RAM501" BSPF1.9230160611¼" BSPF19456224223

        RA50

        Item codeModelOutlet (mm)kWVolt   (v)Flow (l/min)Head (metres)Inlet (mm)Width (mm)Length (mm)Height (mm)Dry weight (kg)
        19-15-1173RA501" BSPF1.9400160611¼" BSPF19456224223
