RS(M) Horizontal Multistage Pumps

Excluding VAT

Description

The RS(M) are non self-priming, multi-stage, horizontal centrifugal pumps. For the pumping of clean water only, they develop high pressures from comparatively small motors and operate virtually silent, hence they are suitable for domestic use, in addition to industrial and horticultural applications. Optional pump control and energy management systems are available (see here).

RSM 40

Item codeModelOutlet (mm)kWVolt (v)Flow (l/min)Head (mtrs)Inlet (mm)Width (mm)Length (mm)Height (mm)Dry weight (kg)
19-15-1046RSM40 1" BSPF1.5230160491¼" BSPF19451424222

RS40

Item code ModelOutlet (mm)kWVolt (v)Flow (l/min)Head (mtrs)Inlet (mm)Width (mm)Length (mm)Height (mm)Dry weight (kg)
19-15-1201RS40 1" BSPF1.5400160491¼" BSPF19451424222

RSM 50

Item code ModelOutlet (mm)kWVolt (v)Flow (l/min)Head (metres)Inlet (mm)Width (mm)Length (mm)Height (mm)Dry weight (kg)
19-15-1052RSM50 1" BSPF1.9230160591¼" BSPF19454324223

RS 50

Item code ModelOutlet (mm)kWVolt (v)Flow (l/min)Head (metres)Inlet (mm)Width (mm)Length (mm)Height (mm)Dry weight (kg)
19-15-1281RS50 1" BSPF1.9400160591¼" BSPF19454324323

RSM 60

Item code ModelOutlet (mm)kWVolt (v)Flow (l/min)Head (metres)Inlet (mm)Width (mm)Length (mm)Height (mm)Dry weight (kg)
19-15-1079RSM60 1" BSPF2.2230160711¼" BSPF19457224224

RS 60

Item code ModelOutlet (mm)kWVolt (v)Flow (l/min)Head (metres)Inlet (mm)Width (mm)Length (mm)Height (mm)Dry weight (kg)
19-15-1143RS60 1" BSPF2.2400160711¼" BSPF19457224224

RS 80

Item code ModelOutlet (mm)kWVolt (v)Flow (l/min)Head (metres)Inlet (mm)Width (mm)Length (mm)Height (mm)Dry weight (kg)
19-15-1074RS80 1" BSPF3400160951¼" BSPF19463024225
