RSX(M)10 Horizontal Multistage Pumps

Excluding VAT


Description

RSXM10 are non self-priming, multi-stage, horizontal centrifugal pumps with all the components that are in contact with the liquid constructed in 304 stainless steel. Mechanical seals are carbon ceramic and NBR.  Motor protection is IP55. Single phase motors incorporate an overload protection device.   They can develop high pressures and lifts from comparatively small motors and operate virtually silent, hence they are suitable for many domestic, industrial and horticultural applications. With the addition of a foot-valve, they are capable of suction lifts of 7 metres. They are designed for pumping clean water only up to a maximum of 35ºC. They are particularly suitable for systems to be controlled by pressure controllers and inverter drives.

RSXM 10-4

Item CodeModelInlet (BSPF)Outlet (BSPF)kWVolt (V)Flow (l/min)Head (mtr)Width (mm)Length (mm)Height (mm)Dry weight (kg)
19-15-1248RSXM10-41½"1½"1.5230V4428016544225419

RSX 10-4

Item  Code ModelInlet (BSPF)Outlet (BSPF)kWVolt (v)Flow (l/min)Head (mtr)Width (mm)Length (mm)Height (mm)Dry weight (kg)
19-15-1259 RSX10-41½"1½"1.5400V4428016544225419

RSXM 10-5

Item  Code ModelInlet (BSPF)Outlet (BSPF)kWVolt (v)Flow (l/min)Head (mtr)Width (mm)Length (mm)Height (mm)Dry weight (kg)
19-15-1083 RSX10-51½"1½"2.2400V5430017051523527

RSX 10-6

Item Code ModelInlet (BSPF)Outlet (BSPF)kWVolts (v)Flow (l/min)Head (mtr)Width (mm)Length (mm)Height (mm)Dry weight (kg)
19-15-1170 RSX10-61½"1½"3400V6530017056223530
