RSX(M)4 Horizontal Multistage Pumps

Excluding VAT

Description

RSXM4 are non self-priming, multi-stage, horizontal centrifugal pumps with all the components that are in contact with the liquid constructed in 304 stainless steel. Mechanical seals are carbon ceramic and NBR.  Motor protection is IP55. Single phase motors incorporate an overload protection device.   They can develop high pressures and lifts from comparatively small motors and operate virtually silent, hence they are suitable for many domestic, industrial and horticultural applications. With the addition of a foot-valve, they are capable of suction lifts of 7 metres. They are designed for pumping clean water only up to a maximum of 35ºC. They particularly suitable for systems to be controlled by pressure controllers and inverter drives.

RSXM 4-3

Item codeModelInlet (BSPF)Outlet (BSPF)KWVolt (v)Flow (l/min)Head (metres)Width (mm)Length (mm)Height (mm)Dry weight (kg)
19-15-1272RSXM4-31¼"1"0.552301603014336221610

RSX 4-3

Item code ModelInlet (BSPF)Outlet (BSPF)KWVolt (v)Flow (l/min)Head (metres)Width (mm)Length (mm)Height (mm)Dry weight (kg)
19-15-1184 RSX4-31¼"1"0.554001603014336221610

RSXM 4-4

Item code ModelInlet (BSPF)Outlet (BSPF)KWVolt (v)Flow (l/min)Head (metres)Width (mm)Length (mm)Height (mm)Dry weight (kg)
19-15-1294 RSXM4-41¼"1"0.752301604014338921610.5

RSX 4-4

Item code ModelInlet (BSPF)Outlet (BSPF)KWVolt (v)Flow (l/min)Head (metres)Width (mm)Length (mm)Height (mm)Dry weight (kg)
19-15-1208 RSX4-41¼"1"0.754001604014338921610.5

RSXM 4-5

Item code ModelInlet (BSPF)Outlet (BSPF)KWVolt (v)Flow (l/min)Head (metres)Width (mm)Length (mm)Height (mm)Dry weight (kg)
19-15-1169 RSXM4-51¼"1"0.752301605014341621611

RSX 4-5

Item code ModelInlet (BSPF)Outlet (BSPF)KWVolt (v)Flow (l/min)Head (metres)Width (mm)Length (mm)Height (mm)Dry weight (kg)
19-15-1210 RSX4-51¼"1"0.754001605014341621611

RSXM 4-6

Item code ModelInlet (BSPF)Outlet (BSPF)KWVolt (v)Flow (l/min)Head (metres)Width (mm)Length (mm)Height (mm)Dry weight (kg)
19-15-1086 RSXM4-61¼"1"1.12301806014344321612

RSX 4-6

Item code ModelInlet (BSPF)Outlet (BSPF)KWVolt (v)Flow (l/min)Head (metres)Width (mm)Length (mm)Height (mm)Dry weight (kg)
19-15-1150 RSX4-61¼"1"1.14001806014344321612
