RV(M) Vertical Multistage Pump

Excluding VAT

Description

The RV(M) are non-self-priming, vertical multi-stage pumps with 304 stainless steel pump casings, cast iron pump bodies and cast iron motor supports. Impellers and diffusers are in thermoplastic. They have 304 stainless steel shafts, fitted with carbon ceramic and NBR mechanical seals.  Motor frame and supports are in aluminium and the fan covers are in steel. Motor protection is IP55.  Single phase motors incorporate an overload protection device. They can develop high pressures and lifts from comparatively small motors and operate virtually silent, hence they are suitable for many domestic, industrial and horticultural applications. They are designed for pumping clean water only up to a maximum of 35ºC.

RVM 40

Item codeModelInlet (BSPF)Outlet (BSPF)KWVolt (V)Flow (l/min)Head (mtrs)Width (mm)Length (mm)Height (mm)Dry weight (kg)
19-15-1127 RVM40 1¼"1"1.5230 1605018124752526

RV 40

Item code
ModelInlet (BSPF)Outlet (BSPF)KWVolt (V)Flow (l/min)Head (mtrs)Width (mm)Length (mm)Height (mm)Packing weight
19-15-1132RV40 1¼"1"1.54001605018124752526

RVM 50

Item code
ModelInlet (BSPF)Outlet (BSPF)KWVolt (V)Flow (l/min)Head (mtrs)Width (mm)Length (mm)Height (mm)Packing weight
19-15-1243RVM50 1¼"1"1.852301606018124755427

RV 50

Item code
ModelInlet (BSPF)Outlet (BSPF)KWVolt (V)Flow (l/min)Head (mtrs)Width (mm)Length (mm)Height (mm)Packing weight
19-15-1064RV50 1¼"1"1.854001606018124755427

RVM 60

Item code
ModelInlet (BSPF)Outlet (BSPF)KWVolt (V)Flow (l/min)Head (mtrs)Width (mm)Length (mm)Height (mm)Packing weight
19-15-1227RVM60 1¼"1"2.22301607318124758328

RV 60

Item Code ModelInlet (BSPF)Outlet (BSPF)KWVolt (V)Flow (l/min)Head (mtrs)Width (mm)Length (mm)Height (mm)Dry weight (kg)
19-15-1017 RV60 1¼"1"2.24001607318124758328

RV 80

Item Code ModelInlet (BSPF)Outlet (BSPF)KWVolt (V)Flow (l/min)Head (mtrs)Width (mm)Length (mm)Height (mm)Dry weight (kg)
19-15-1214RV80 1¼"1"34001809818124764132
