SFQ Submersible Marine Pumps

Excluding VAT

Description

The SFQ series features all wetted parts in 316 grade (1.4436) cast stainless steel, for industrial pumping of aggressive liquids. 316 is commonly known as “marine grade” hence these pumps are suitable for seawater and salt water, so the cast construction, is extremely resilient during prolonged use in these liquids and also many chemical solutions. To maximise performance in seawater, we recommend fitting sacrificial anodes. Available in three phase only, they are fitted with high-performance motors.



316 stainless steel is used widely in marine applications, but its corrosion resistance in contact with seawater is limited, so it cannot be considered ‘corrosion proof’. The corrosion risks increase with the effects of chloride concentrations, evaporation, temperature, aeration etc, (working individually or together); hence, the guarantee period for these models relates to the mechanical operation and may not cover all seawater conditions. The selection of a pump for a chemical application must initially meet the basic corrosion resistant standards, however additional mechanical or physical properties in the duty may also need to be considered to achieve the overall service performance required. In each case, please contact our sales department for guidance.

50SFQ2.75

item code model Manual or Auto outlet (mm/fbsp) kW volt flow (l/min) head (mtrs) free passage (mm) w x l x h (mm) dry weight (kgs)
10-10-1124 50SFQ2.75 50 0.75 400 428 14.3 196x252x397 20

    80SFQ27.5

    item code model Manual or Auto outlet (mm/fbsp) kW volt flow (l/min) head (mtrs) free passage (mm) w x l x h (mm) dry weight (kgs)
    10-10-1131 80SFQ27.5 3" 7.5 400 1995 35.1 30 360x635x844 123

      80SFQ211

      item code model Manual or Auto outlet (mm/fbsp) kW volt flow (l/min) head (mtrs) free passage (mm) w x l x h (mm) dry weight (kgs)
      10-10-1277 80SFQ211 3" 11 400 1949 43.9 30 360x635x892 143
