UZ Submersible Sewage Pump

Excluding VAT



Description

The UZ series have vortex impellers and wide pump casings, for pumping large volumes of sewage and waste which contains fibrous material, submerged debris and very large solids. Construction is in cast iron and they are fitted with high-performance, 4 pole motors, to give improved longevity and wear resistance. Available in three-phase only. They are supplied with a bare delivery flange; elbows (for free-standing use) and auto-coupling sets (for guide rail applications), are optional extras (see here).



When a Tsurumi sewage pump is being selected as a replacement for an existing Flygt pump installation, a guide hook adaptor is available as an optional extra. This is suitable for use with all 3” and 4” sewage pumps and permits retro-fitting a Tsurumi to existing Flygt guide rail installations.

100UZ47.5

Item Code

Model

Bore (mm)

KW

Volt (v)

Flow (I/min)

Head (mtrs)

Free Passage (mm)

W x L x H (mm)

Dry Weight (kgs)

10-10-1075

100UZ47.5

100

7.5

400

2500

15.5

100

358x652x960

150

100UZ411

Item Code

Model

Bore (mm)

KW

Volt (v)

Flow (I/min)

Head (mtrs)

Free Passage (mm)

W x L x H (mm)

Dry Weight (kgs)

10-10-1048

100UZ411

100

11

400

2600

19

100

358x660x1021

178

50UZ41.5

 item code model bore (mm) kW volt flow (l/min) head (mtrs) free passage (mm) w x l x h (mm) *inc elbow dry weight (kgs)
10-10-1271 50UZ41.5 50 1.5 400 640 10.2 50 250x405x566 52
