KTZE Automatic Heavy-Duty Drainage Sump Pump

Excluding VAT

Description

The KTZE pumps offer an automatic option to the KTZ series, without the need for external control panels and cumbersome float switches. A sensor probe is mounted in a durable, moulded rubber bracket and, for added protection, it is positioned within the footprint of the pump base. Once the water level reaches the probe, the pump will start and continue to operate for one minute after the water falls below it. However, if the water level touches the probe within this time, the “stop” signal is cancelled and the pump continues to run until the water is cleared. To enable a lower “on level” (by a further 90mm), the sensor probe can be lengthened by fitting the electrode extender (part no: 090-126-15), which is an optional extra.

All models are supplied with 20 metres of heavy duty, rubber power cable, although IDS (individually screened cable) is available on 3.7kW pumps, at an extra cost, for quarry and mining applications. All pumps are supplied with a threaded outlet and a hose connector.

KTVE21.5

Item CodeModelOutlet (mm)kWVolts (v)Flow (l/min)Head (metres)Free Passage (mm)Width (mm)Length (mm)Height (mm)On Level (mm)Off Level (mm)Dry weight (kg)
10-10-1068KTZE21.5 - 400V - Auto2" & 501.5400425218.521623560934512040

KTVE31.5

Item CodeModelOutlet (mm)kWVolts (v)Flow (l/min)Head (metres)Free Passage (mm)Width (mm)Length (mm)Height (mm)On Level (mm)Off Level (mm)Dry weight (kg)
10-10-1010KTZE31.5 - 400V - Auto3" & 801.5400670148.521623560934512039

KTVE22.2

Item CodeModelOutlet (mm)kWVolts (v)Flow (l/min)Head (metres)Free Passage (mm)Width (mm)Length (mm)Height (mm)On Level (mm)Off Level (mm)Dry weight (kg)
10-10-1109KTZE22.2 - 400V - Auto2" & 502.2400500268.521623562935512042

KTVE32.2

Item CodeModelOutlet (mm)kWVolts (v)Flow (l/min)Head (metres)Free Passage (mm)Width (mm)Length (mm)Height (mm)On Level (mm)Off Level (mm)Dry weight (kg)
10-10-1226KTZE32.2 - 400V - Auto3" & 802.2400800208.521623562935512041

KTVE23.7

Item CodeModelOutlet (mm)kWVolts (v)Flow (l/min)Head (metres)Free Passage (mm)Width (mm)Length (mm)Height (mm)On Level (mm)Off Level (mm)Dry weight (kg)
10-10-1119KTZE23.7 - 400V - Auto2" & 503.7400440378.525228374743515071

KTVE33.7

Item CodeModelOutlet (mm)kWVolt (v)Flow (l/min)Head (metres)Free Passage (mm)Width (mm)Length (mm)Height (mm)On Level (mm)Off Level (mm)Dry weight (kg)
10-10-1122KTZE33.7 - 400V - Auto3" & 803.7400900298.525228375743515071

KTVE43.7

Item CodeModelOutlet (mm)kWVolt (v)Flow (l/min)Head (metres)Free Passage (mm)Width (mm)Length (mm)Height (mm)On Level (mm)Off Level (mm)Dry weight (kg)
10-10-1101KTZE43.7 - 400V - Auto4" & 1003.74001430188.525228376743515071
